Chapter 5 Devices
5-5
5__
_
Special
D
Content
OFF
ON
STOP
RUN
RUN
STOP
Attrib.
Latched
Default
D1043
Order of the 4
th
Step switching to ON
0
-
-
R
NO
0
D1044
Order of the 5
th
Step switching to ON
0
-
-
R
NO
0
D1045
Order of the 6
th
Step switching to ON
0
-
-
R
NO
0
D1046
Order of the 7
th
Step switching to ON
0
-
-
R
NO
0
D1047
Order of the 8
th
Step switching to ON
0
-
-
R
NO
0
D1049 Number of the Alarm switiching to ON 0 - - R NO 0
D1050
D1055
Convert data for Modbus communication;
PLC automatically converts the ASCII data in
D1070~D1085 into Hex data and stores the 16-bit Hex
data into D1050~D1055
0 - - R NO 0
D1062 Average of DRV analog input times (TP04P-20EXL1T) - - - R/W YES 2
D1067 Error code for program execution error 0 0 - R NO 0
D1068 Address of program execution error 0 - - R NO 0
D1070
D1085
Feedback data (ASCII) of Modbus communication;
When PLC’s RS-485 communication instruction receives
feedback signals, the data will be saved in the registers
D1070~D1085. Usres can check the received data in
these registers.
0 - - R NO 0
D1089
D1099
Sent data of Modbus communication.
When PLC’s RS-485 communication instruction sends
out data, the data will be stored in D1089~D1099. Users
can check the sent data in these registers.
0 - - R NO 0
D1110
Average value of analog input channel 0 (AD 0) When
average times in D1062 is set to 1, D1110 indicates
present value.
0 - - R NO #
D1111
Average value of analog input channel 1 (AD 1) When
average times in D1062 is set to 1, D1111 indicates
present value
0 - - R NO #
D1112
Average value of analog input channel 2 (AD 2)
Whenaverage times in D1062 is set to 1, D1112 indicates
present value
0 - - R NO #
D1113
Average value of analog input channel 3 (AD 3)
Whenaverage times in D1062 is set to 1, D1113 indicates
present value
0 - - R NO #
D1114
Analog input/output setting mode (TP04P-20EXL1T)
Bit
11-10
9-8
7-6
Channel DA5 DA4 AD3
Bit 5-4 3-2 1-0
Channel AD2 AD1 AD0
Input setting mode:
00: Voltage mode (-10V ~ 10V)
01: Current mode (-20mA ~ 20mA)
10: Current mode (4 ~ 20mA)
Output setting mode:
- - - R/W YES 0
