TP70P-211LC1T/TP04P-20EXL1T Operation Manual
5-6
_5
Special
D
Content
OFF

ON
STOP

RUN
RUN

STOP
Attrib. Latched Default
00: Voltage mode (-10V ~ 10V)
01: Current mode (0mA ~ 20mA)
10: Current mode (4 ~ 20mA)
D1116 Setting value of analog output channel 0 (DA 4) 0 0 0 R/W NO 0
D1117 Setting value of analog output channel 1 (DA 5) 0 0 0 R/W NO 0
D1118
TP04P-20EXL1T
Sampling time of analog/digital converstion; unit: 1 ms. If
D1118 is ≦2, sampling time default is 2 ms.
2 - - R/W YES 2
D1120 Setting for COM2 (RS-485) communication protocol H’86 - - R/W NO H’86
D1121 COM2(RS-485) PLC communication address - - - R/W YES 1
D1122
COM2(RS-485) Residual number of words of transmitting
data
0 0 - R NO 0
D1123
COM2(RS-485) Residual number of words of the
receiving data
0 0 - R NO 0
D1124 COM2(RS-485) Definition of start character (STX) H’3A - - R/W NO H’3A
D1125
COM2(RS-485) Definition of first ending character
(ETX1)
H’0D - - R/W NO H’0D
D1126
COM2(RS-485) Definition of second ending character
(ETX2)
H’0A - - R/W NO H’0A
D1129 COM2 (RS-485) Communication time-out setting (ms) 0 - - R/W NO 0
D1130 COM2 (RS-485) Error code returning from Modbus 0 - - R NO 0
D1137 Address where incorrect use of operand occurs 0 0 - R NO 0
D1140 Number of Analog I/O modules (max. 1) - - - R NO 1
D1142
Digital input points (X point)
TP70P-211LC1T: 17
TP04P-20EXL1T: 9
# - - R NO #
D1143
Digital output points (Y point)
TP70P-211LC1T: 24
TP04P-20EXL1T: 16
# - - R NO #
D1168
When RS instruction this speficied end word, it triggers an
interruption request (I150) on COM2 (RS-485).
0 - - R/W NO 0
D1182 Index register E1 0 - - R/W NO 0
D1183 Index register F1 0 - - R/W NO 0
D1184 Index register E2 0 - - R/W NO 0
D1185 Index register F2 0 - - R/W NO 0
D1186 Index register E3 0 - - R/W NO 0
D1187 Index register F3 0 - - R/W NO 0
D1188 Index register E4 0 - - R/W NO 0
