Chapter 5 Devices
5-7
5__
_
Special
D
Content
OFF

ON
STOP

RUN
RUN

STOP
Attrib. Latched Default
D1189 Index register F4 0 - - R/W NO 0
D1190 Index register E5 0 - - R/W NO 0
D1191 Index register F5 0 - - R/W NO 0
D1192 Index register E6 0 - - R/W NO 0
D1193 Index register F6 0 - - R/W NO 0
D1194 Index register E7 0 - - R/W NO 0
D1195 Index register F7 0 - - R/W NO 0
D1240
When interupt I100/I101 occurs, D1240 stores the low
word of high-speed counter.
0 0 - R NO 0
D1241
When interupt I100/I101 occurs, D1240 stores the high
word of high-speed counter.
0 0 - R NO 0
D1256
↓
D1295
For COM2 RS-485 MODRW instruction. D1256~D1295
store the sent data of MODRW instruction. When
MODRW instruction sends out data, the data will be
stored in D1256~D1295. Users can check the sent data in
these registers.
0 - - R NO 0
D1296
↓
D1311
For COM2 RS-485 MODRW instruction. D1296~D1311
store the converted hex data from D1070 ~ D1085
(ASCII). PLC automatically converts the received ASCII
data in D1070 ~ D1085 into hex data.
0 - - R NO 0
D1313 Second of RTC: 00 ~ 59 - - - R/W YES #
D1314 Minute of RTC: 00 ~ 59 - - - R/W YES #
D1315 Hour of RTC: 00 ~ 23 - - - R/W YES #
D1316 Day of RTC: 01 ~ 31 - - - R/W YES #
D1317 Month of RTC: 01 ~ 12 - - - R/W YES #
D1318 Week of RTC: 1 ~ 7 - - - R/W YES #
D1319 Year of RTC: 00 ~ 99 (A.D.) - - - R/W YES #
D1320
DRV BD module code
TP04P-20EXL1T: H’22
TP70P-211LC1T: H’16
- - - R NO
H’22
H’16
D1321
IO BD module code
TP04P-20EXL1T: H’9C
TP70P-211LC1T: H’9C
- - - R NO H’9C
D1354
PLC Link scan cycle (Unit: 1ms)
 Max: K32000
 D1354 = K0 when PLC Link stops or when the first
scan is complete
0 0 0 R NO 0
D1355 Starting reference for Master to read from Slave ID#1 - - - R/W YES H’1064
D1356 Starting reference for Master to read from Slave ID#2 - - - R/W YES H’1064
