TP70P-211LC1T/TP04P-20EXL1T Operation Manual
5-22
_5
Special
D
Item Description Attibutes Default
K23: Ni100
K24: Ni1000
K25: LG-Ni1000
K28: -100 ~ 100mV (Supported by V1.02 and
after)
D4324 AX CH1 measurement unit
K0: ℃; K1: ℉
R/W O K0
D4325
AX CH1 offset
K-999 ~ K999
R/W
O
K0
D4330 AX CH2 PV
Present weight value of CH2; when the value is
K-32765 (H8002), it indicates an error occurs
and temperature cannot be obtained
R X --
D4333 AX CH2 sensor type
K-1: channel closed
K0: 0 ~ 5V (default)
K1: 0 ~ 10V
K2: 0 ~ 20 mA
K3: 4 ~ 20 mA
K4: 0 ~ 50 mV
K5: Pt100
K6: JPt100
K7: Pt1000
K21: Cu50
K22: Cu100
K23: Ni100
K24: Ni1000
K25: LG-Ni1000
K28: -100 ~ 100mV (Supported by V1.02 and
after)
R/W O K0
D4334 AX CH2 measurement unit
K0: ℃; K1: ℉
R/W O K0
D4335
AX CH2 offset
K-999 ~ K999
R/W
O
K0
D4340 AX error code
b1: Error exists in the module hardware
b2: Conversion error in channel 1
b3: Conversion error in channel 2
R X --
D4350 IO1 analog output mode
K0: 4 ~ 20 mA (default)
K1: 0 ~ 20 mA
R/W O K0
D4351 IO2 analog output mode
K0: 4 ~ 20 mA (default)
K1: 0 ~ 20 mA
R/W O K0
D4352 IO3 analog output mode
K0: 4 ~ 20 mA (default)
K1: 0 ~ 20 mA
R/W O K0
D4353 IO4 analog output mode
K0: 4 ~ 20 mA (default)
K1: 0 ~ 20 mA
R/W O K0
D4530 Eigenvalue Refer to section 3.1.1 for details R/W
◎
K1
D4531 Weight measured time
K0: 2.5 ms
K1: 10 ms
K2: 16 ms
K3: 20 ms
K4: 50 ms (default)
K5: 60 ms
K6: 100 ms
R/W
◎
K4
