Chapter 10 Auto-tuning Process | VFD-ED
10: User-defined low-voltage detection (LV)
11: Malfunction indication
12: Mechanical brake release (Pr.02-29, Pr.02-30, Pr.02-37)
13: Overheat (Pr.06-14)
14: Brake transistor signal
15: Motor-controlled magnetic contactor output
16: Slip error (oSL)
17: Malfunction indication 1
18: Reserved
19: Brake transistor output error
20: Warning output
21: Over-voltage warning
22: Over-current stall prevention warning
23: Over-voltage stall prevention warning
24: Operation mode indication (Pr.00-15=1)
25: Forward command
26: Reverse command
27: Output when current ≥ Pr.02-33
28: Output when current < Pr.02-33
29: Output when frequency ≥ Pr.02-34
30: Output when frequency < Pr.02-34
31: Power generation direction and status verification
32: Power generation direction
33: Zero speed (actual output frequency)
34: Zero speed with Stop (actual output frequency)
35: Fault output option 1 (Pr.06-22)
36: Fault output option 2 (Pr.06-23)
37: Fault output option 3 (Pr.06-24)
38: Fault output option 4 (Pr.06-25)
39: Reserved
40: Speed reached (including zero speed)
41: Reserved
42: STO Output Error
43–44: Direct Docking Mode only
45: Reserved
46: Retrying after a fault has occurred indication
47: Direct Docking Mode only
48: Control output of MPSCC (Motor Phase Short Circuit Contactor)
49: Emergency power mode action
50: Speed reached Pr.02-34
51: Brake torque test finished
52: AFE reset
