Delta VFD-ED Series

Chapter 11 Summary of Parameter Settings | VFD-ED
11-25
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
Status when the Most
Recent Fault Occurred
only
06-63
Multi-output Terminals
status when the Most
Recent Fault Occurred
0000h–FFFFh
Read
only
○ ○ ○ ○ ○
06-64
Motor Drive Status when
the Most Recent Fault
Occurred
0000h–FFFFh
Read
only
○ ○ ○ ○ ○
 06-68
Power Factor Angle Level
for Power Generation
Direction
0.0–150.0〫 70.0 ○ ○ ○ ○ ○
06-69
Reference Level for
Power Factor Angle
during Operation
-200.0–200.0〫
Read
only
○ ○ ○ ○ ○
06-70
Power Generation
Direction
0: FWD
1: REV
Read
only
○ ○ ○ ○ ○

06-71
UPS Output Delay Time
0.0–10.0 sec.
1.0
○
○
○
○
○
06-72
UPS Stops Output Delay
Time
0.0–60.0 sec. 3.0 ○ ○ ○ ○ ○
06-73
Permanent Operation
Direction Count (H)
0–60000
Read
only
○ ○ ○ ○ ○
06-74
Permanent Operation
Direction Count (L)
0–9999
Read
only
○ ○ ○ ○ ○
06-75
Single Operation
Direction Count (H)
0–20
Read
only
○ ○ ○ ○ ○
06-76
Single Operation
Direction Count (L)
0–9999
Read
only
○ ○ ○ ○ ○
06-77
Number of Times for
Single Operation Reset
0–100
Read
only
○ ○ ○ ○ ○
06-78
Number of Times for
Operation Direction
0.00–200.00 k 2.00 ○ ○ ○ ○ ○
06-79
Function Selection for
Operation Times
0–2 0 ○ ○ ○ ○ ○
06-80
Output Frequency when
Fault 2 Occurred
0.00–655.35 Hz
Read
only
○ ○ ○ ○ ○
06-81
DC Bus Voltage when
Fault 2 Occurred
0.0–6553.5 V
Read
only
○ ○ ○ ○ ○
06-82
Output Current when
Fault 2 Occurred
0.00–655.35 Amps
Read
only
○ ○ ○ ○ ○
06-83
IGBT Temperature when
Fault 2 Occurred
-3276.8–3276.7ºC
Read
only
○ ○ ○ ○ ○
06-84
Output Frequency when
Fault 3 Occurred
0.00–655.35 Hz
Read
only
○ ○ ○ ○ ○
06-85
DC Bus Voltage when
Fault 3 Occurred
0.0–6553.5 V
Read
only
○ ○ ○ ○ ○
06-86
Output Current when
0.00–655.35 Amps
Read
○
○
○
○
○
