Delta VFD-ED Series

Chapter 11 Summary of Parameter Settings | VFD-ED
11-32
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
 10-11
ASR (Auto Speed
Regulation) Control (P) of
Zero Speed
0.0–1000.0% 100.0 ○ ○ ○ ○ ○
 10-12
ASR (Auto Speed
Regulation) Control (I) of
Zero Speed
0.000–10.000 sec. 0.100 ○ ○ ○ ○ ○
 10-13
ASR (Auto Speed
Regulation) Control (P) 1
0.0–1000.0% 100.0 ○ ○ ○ ○ ○
 10-14
ASR (Auto Speed
Regulation) Control (I) 1
0.000–10.000 sec. 0.100 ○ ○ ○ ○ ○
 10-15
ASR (Auto Speed
Regulation) Control (P) 2
0.0–1000.0% 100.0 ○ ○ ○ ○ ○
 10-16
ASR (Auto Speed
Regulation) Control (I) 2
0.000–10.000 sec. 0.100 ○ ○ ○ ○ ○
 10-17
ASR 1/ ASR2 Switch
Frequency
0.00–299.00 Hz (0: Disable) 7.00 ○ ○ ○ ○ ○
 10-18
ASR Primary Low Pass
Filter Gain
0.001–0.350 sec. 0.008 ○ ○ ○ ○ ○
 10-19
Zero Speed Position
Control Gain (P)
0.00–655.00% 80.00 ○
 10-20
Low Speed ASR Width
Adjustment
0.00–299.00 Hz 5.00 ○ ○ ○
 10-21
High Speed ASR Width
Adjustment
0.00–299.00 Hz 5.00 ○ ○ ○
 10-22
Zero Speed Position
Control Holding Time
0.001–65.535 sec. 0.250 ○
 10-23
Zero Speed Position
Control Low Pass Filter
Time
0.001–65.535 sec. 0.004 ○
 10-24
Zero Speed Position
Control Activation Mode
Selection
0: After the brake release set in
Pr.02-29
1: After the brake signal input (Pr.02-
01–Pr.02-08 is set to 42)
0 ○
 10-25
Elevator Leveling
(Zero Speed Gain P)
0.0–1000.0% 100.0 ○ ○ ○ ○ ○
 10-26
Elevator Leveling
(Zero Speed Integral I)
0.000–10.000 sec. 0.100 ○ ○ ○ ○ ○
 10-27
Elevator Starting
(Zero Speed Gain P)
0.0–1000.0% 100.0 ○ ○ ○ ○ ○
 10-28
Elevator Starting
(Zero Speed Integral I)
0.000–10.000 sec. 0.100 ○ ○ ○ ○ ○
 10-29
PG Card Frequency
Division Output
0–31 0 ○ ○ ○
 10-30
PG Card Frequency
Division Output Type
0000h–0008h 0000h ○ ○ ○
10-31
PG Card C+/C-
0000h–0001h
0000h
