10 Feedback Control Parameters
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
10-00 Selection of Encoder
0: Disable
1: ABZ
2: ABZ+Hall
3: SIN/COS+Sinusoidal
4: SIN/COS+Endat
5: SIN/COS
6: SIN/COS+Hiperface
0 ○ ○ ○
10-01
Encoder PPR
1–25000
2048
○
○
○
10-02 Encoder Input Type Setting
0: Disable
1: Phase A leads in a forward run
command and phase B leads in a
reverse run command
2: Phase B leads in a forward run
command and phase A leads in a
reverse run command
3: Phase A is a pulse input and
phase B is a direction input (low
input = reverse direction, high
input = forward direction)
4: Phase A is a pulse input and
phase B is a direction input (low
input = forward direction, high
input = reverse direction)
5: Single-phase input
0 ○ ○ ○
 10-03
Encoder Feedback Signal
Fault Action (PGF1, PGF2)
0: Warn and keep operation
1: Fault and ramp to stop
2: Fault and stop operation
2 ○ ○ ○
 10-04
Encoder Feedback Signal
Fault Detection Time
0.0–10.0 sec. 1.0 ○ ○ ○
 10-05
Encoder Stall Level
(PGF3)
0–120% (0: Disable) 115 ○ ○ ○ ○
 10-06
Encoder Stall Detection
Time
0.0–2.0 sec. 0.1 ○ ○ ○ ○
 10-07
Encoder Slip Range
(PGF4)
0–50% (0: Disable) 50 ○ ○ ○ ○
 10-08
Encoder Slip Detection
Time
0.0–10.0 sec. 0.5 ○ ○ ○ ○
 10-09
Encoder Stall and Slip
Error Action
0: Warn and keep operation
1: Fault and ramp to stop
2: Fault and stop operation
2 ○ ○ ○ ○
10-10
Mode Selection for UVW
Input
0: Z signal is at the falling edge of U-
phase
1: Z signal is at the rising edge of U-
phase
0 ○ ○ ○
