12 Descriptions of Parameter Settings | VFD-ED
12-06-9
Bit 3 Bit 2 Bit 1 Bit 0 Fault Code
- - - - 86: Leveling switch short-circuited (LSS)
- - - - 87: Leveling switch open-circuited (LSo)
1 0 0 0 94: BTTx Fail (btt)
1 0 0 0 95: BTTx Error (bttE)
Fault Output Option 1
Fault Output Option 2
Fault Output Option 3
Fault Output Option 4
Control Mode
VF VFPG SVC FOCPG FOCPM Default: 0
Settings 0–65535 sec. (refer to bit table for fault code)
You can use these parameters with multi-function output (set Pr.02-11Pr.02-22 to 3538) for the specific
requirement. When a fault occurs, the corresponding terminals are activated. You must convert binary
value to decimal value when setting Pr.06-22Pr.06-25.
Fault Code
Bit0 Bit1 Bit2 Bit3 Bit4 Bit5 Bit6
current Volt. OL SYS FBK EXI CE
0: No fault
1: Over-current during acceleration (ocA)
2: Over-current during deceleration (ocd)
3: Over-current during constant speed (ocn)
4: Ground fault (GFF)
5: IGBT short-circuit (occ)
6: Over-current at stop (ocS)
7: Over-voltage during acceleration (ovA)
8: Over-voltage during deceleration (ovd)
9: Over-voltage during constant speed (ovn)
10: Over-voltage at stop (ovS)
11: Low voltage during acceleration (LvA)
12: Low voltage during deceleration (Lvd)
13: Low voltage during constant speed (Lvn)
14: Low voltage at stop (LvS)
15: Input phase loss (PHL)
16: IGBT overheat (oH1)
17: Bulk capacitor overheat (oH2)
18: Abnormal IGBT temperature detected
(tH1o)
19: Abnormal bulk capacitor temperature
detected (tH2o)
20: Unusual cooling fan operation (FAn)
21: Overload (oL) (150%; 1 minute, motor
drive overloaded)
22: Motor overload (EoL1)
23: Reserved
24: Motor PTC overheat (oH3)
