Fault Code
Bit0 Bit1 Bit2 Bit3 Bit4 Bit5 Bit6
current Volt. OL SYS FBK EXI CE
25: Reserved
26: Over-torque 1 (ot1)
●
27: Over-torque 2 (ot2)
●
28: Reserved
29: Reserved
30: Memory writing error (cF1)
●
31: Memory reading error (cF2)
●
32: Isum current detection error (cd0)
●
33: U-phase current detection error (cd1)
●
34: V-phase current detection error (cd2)
●
35: W-phase current detection error (cd3)
●
36: cc (current clamp) hardware error (Hd0) ●
37: oc (over-current) hardware error (Hd1)
●
38: ov (over-voltage) hardware error (Hd2)
●
39: GFF (ground fault) hardware error (Hd3) ●
40: Auto-tuning error on motor’s parameter
(AUE)
●
41: Reserved ●
42: PG feedback error (PGF1) ●
43: PG feedback loss (PGF2) ●
44: PG feedback stall (PGF3) ●
45: PG slip error (PGF4) ●
46: Reserved ●
47: Reserved ●
48: Reserved ●
49: External fault input (EF) ●
50: Emergency stop from external terminals
(EF1)
●
51: Reserved
52: Password error after three attempts
(Pcod)
●
53: Reserved
54: Illegal communication command (cE01) ●
55: Illegal communication address (cE02) ●
56: Communication data length error (cE03) ●
57: Communication attempts to write to a
read-only address (cE04)
●
58: Modbus transmission time-out (cE10) ●
59: Keypad transmission time-out (cP10) ●
60: Brake transistor error (BF)
●
61–62: Reserved
63: Reserved ●
64: Mechanical brake feedback error (MBF)
●
65: PG hardware error (PGF5) ●
66: Magnetic contactor error (MCF) ●
67: Output phase loss (MPHL)
●
