Chapter 6 Optional Accessories | VFD-ED
Model
Current
Current
Output Reactors
Reactors
Reactors
4% DC Reactors
(Delta Part #)
VFD150ED23 58 116 0.162
DR065AP162
DR065LP162
0.432 DR065DP432
VFD185ED23 77 154 0.141
DR090AP141
DR090LP141
0.325 DR090DP325
VFD220ED23 87 174 0.141
DR090AP141
DR090LP141
0.325 DR090DP325
VFD300ED23 132 264 0.087
DR146AP087
DR146LP087
NA** NA**
VFD370ED23 161 322 0.07
DR180AP070
DR180LP070
NA** NA**
NOTE: NA* stands for not being able to install this accessory; NA** stands for built-in accessory.
Table 6-9
380V–460V / 50–60 Hz (Three-phase power)
Model
Rated
Current
(Arms)
Current
(Arms)
3% AC Input /
Output Reactors
(mH)
3% AC Input / Output
Reactors
(Delta Part #)
4% DC
Reactors
(mH)
4% DC Reactors
(Delta Part #)
VFD040ED43S 11.5 23 2.31
DR010A0231
DR010L0231
NA* NA*
VFD055ED43S 13 26 2.02
DR012A0202
DR012L0202
4.67 DR012D0467
VFD075ED43S 17 34 1.17
DR018A0117
DR018L0117
3.11 DR018D0311
VFD110ED43S 23 46 0.881
DR024AP881
DR024LP881
2.33 DR024D0233
VFD150ED43S 30 60 0.66
DR032AP660
DR032LP660
1.75 DR032D0175
VFD185ED43S 38 76 0.639
DR038AP639
DR038LP639
1.47 DR038D0147
VFD220ED43S 45 90 0.541
DR045AP541
DR045LP541
1.24 DR045D0124
VFD300ED43S 58 116 0.405
DR060AP405
DR060LP405
0.935 DR060DP935
VFD370ED43S 80 160 0.267
DR091AP267
DR091LP267
NA** NA**
VFD450ED43S 100 200 0.221
DR110AP221
DR110LP221
NA** NA**
VFD550ED43S 128 256 0.162
DR150AP162
DR150LP162
NA** NA**
VFD750ED43S 165 330 0.135
DR180AP135
DR180LP135
NA** NA**
NOTE: NA* stands for not being able to install this accessory; NA** stands for built-in accessory.
Table 6-10
NOTE:
Because Delta’s three-phase power drive models fulfill the requirement for EN12015:2014
Section 6.6.3 condition a), and in accordance with EN12015:2014 Section 6.7.2 Table 4, use THD
<48% to comply with EN12015:2014.
