Chapter 6 Optional Accessories | VFD-ED
6-15
Figure 6-10
Unit: mm
Input Reactors
Delta Part #
DR075AP170 See above.
Table 6-14
PE M8 x 23
Tightening torque: 6±0.3 Nm
Terminal gauge: 4 mm
2
Tightening torque: 0.8–1.0 Nm
