Chapter 6 Optional Accessories | VFD-ED

6-14

Figure 6-9

Unit: mm

Input Reactors

Delta Part #

DR065AP162 See above.

Table 6-13

Installing screw: M6

Tightening torque: 3±1.5 Nm

PE M6
