Chapter 6 Optional Accessories | VFD-ED
6-17
Figure 6-12
Unit: mm
Input Reactors
Delta Part #
DR105AP106 See above.
Table 6-16
Terminal gauge: 4 mm
2
Tightening torque: 0.8–1.0 Nm
PE M8 x 23
Tightening torque: 6±0.3 Nm
