Delta VFD-ED Series User Manual

Chapter 6 Optional Accessories | VFD-ED
6-25
DC reactor dimension and specifications:
Figure 6-20
Unit: mm
DC Reactors
Delta Part #
A B C D E R
DR005D0585
79
78
112
64±2
56±2
9.5*5.5
DR008D0366
79
78
112
64±2
56±2
9.5*5.5
DR011D0266
79
92
112
64±2
69.5±2
9.5*5.5
DR017D0172
79
112
112
64±2
89.5±2
9.5*5.5
DR025D0117
99
105
128
79±2
82.5±2
9.5*5.5
DR033DP851
117
110
156
95±2
87±2
10*6.5
DR049DP574
117
120
157
95±2
97±2
10*6.5
DR065DP432
117
140
157
95±2
116.5±2
10*6.5
DR075DP391
136
135
178
111±2
112±2
10*6.5
DR090DP325
136
135
179
111±2
112±2
10*6.5
DR003D1870
79
78
112
64±2
56±2
9.5*5.5
DR004D1403
79
92
112
64±2
69.5±2
9.5*5.5
DR006D0935
79
92
112
64±2
69.5±2
9.5*5.5
DR009D0623
79
112
112
64±2
89.5±2
9.5*5.5
DR010D0534
99
93
128
79±2
70±2
9.5*5.5
DR012D0467
99
105
128
79±2
82.5±2
9.5*5.5
DR018D0311
117
110
144
95±2
87±2
10*6.5
DR024D0233
117
120
144
95±2
97±2
10*6.5
DR032D0175
117
140
157
95±2
116.5±2
10*6.5
DR038D0147
136
135
172
111±2
112±2
10*6.5
DR045D0124
136
135
173
111±2
112±2
10*6.5
DR060DP935
136
150
173
111±2
127±2
10*6.5
Table 6-24
C
A
D
E
B
R
