Chapter 6 Optional Accessories | VFD-ED
6-40
EMC Filter Model #: EMF056A23A Unit: mm [inch]
Figure 6-36
155.0 [6.10]
110.0 [4.33]
390.0 [15.35]
5.5 [0.22]
375.0 [14.76]
110.0 [4.33]
5.5 [0.22]
5.5 [0.22]
5.5 [0.22]
375.0 [14.76]
28.0 [1.10]33.0 [1.30]
28.0 [1.10]
33.0 [1.30]
80.0 [3.15]
