Chapter 1 Introduction



VFD-EL-W

1-4

Frame B

input terminals

(R/L1, S/L2, T/L3)

frequency

control knob

digital keypad

case

control board

cover

output terminals

(U/T1, V/T2, W/T3)

grounding terminal

digital keypad

choose NPN/ PNP

choose AVI/ ACI

control terminals

RS485 terminal

(RJ45)
