Chapter 4 Parameters
VFD-EL-W
4-53
04.19
MI Terminal Control Mode Selection
Default: 0
Settings
0: Mode 1
(MI1: Start-up/Stop terminal; MI2 & MI3: multi-
function input terminals)
1: Mode 2
(MI1/MI2/MI3 support two-wire/three-wire start-up)
Determines the MI terminal control modes.
Mode 1: MI1 is the start-up/stop terminal; MI2 and MI3 are the multi-function input terminals.
Mode 2: MI1, MI2 and MI3 support the two-wire / three-wire start-up.
04.20
Reserved
04.21
Reserved
04.22
Reserved
04.23
Reserved
04.24
Reserved
04.25
Reserved
04.04
Start-up / Stop Method of MI Terminals and Multi-function Input Selection
Default: 0
Settings
