Delta VFD040EL43W User Manual

Appendix B Accessories  VFD-EL-W
B-2
B.2 Reactor
B.2.1 AC Reactor
AC Input Reactor Recommended Value
230V, 50/60Hz, One-Phase
kW HP
Fundamental
Amps
Max. continuous
Amps
Inductance (mH)
3–5% Impedance
0.2 0.25 4 6 6.5
0.4 0.5 5 7.5 3
0.75 1 8 12 1.5
1.5 2 12 18 1.25
2.2 3 18 27 0.8
460V, 50/60Hz, Three-Phase
kW HP
Fundamental
Amps
Max. continuous
Amps
Inductance (mH)
3% Impedance 5% Impedance
0.4 0.5 2 3 20 32
0.75 1 4 6 9 12
1.5 2 4 6 6.5 9
2.2 3 8 12 5 7.5
4.0 5.5 8 12 3 5
AC Output Reactor Recommended Value
230V, 50/60Hz, Three-Phase
kW HP
Fundamental
Amps
Max. continuous
Amps
Inductance (mH)
3% Impedance 5% Impedance
0.2
0.25 4 6 9
12
0.4
0.5 4 6 6.5
9
0.75
1 8 12 3
5
1.5
2 8 12 1.5
3
2.2
3 12 18 1.25
2.5
460V, 50/60Hz, Three-Phase
kW HP
Fundamental
Amps
Max. continuous
Amps
Inductance (mH)
3% Impedance 5% Impedance
0.4
0.5
2 3 20 32
0.75
1
4 6 9 12
1.5
2
4 6 6.5 9
2.2
3
8 12 5 7.5
4.0
5.5
12 18 3 5
