Delta VFD220VL43C-J User Manual

Chapter 4 Description of Parameters | VFD-VJ
4-36
01 Motor Parameters  You can set this parameter during operation.
Control mode
Control mode
VF FOCPG FOCPM
Factory setting: 5
Settings
0：V/F
1: Reserved
2: Reserved
3: FOCPGIM (Induction Motor)
4: Reserved
5: FOCPGPM (Synchronous Motor)
6: Reserved
7: Reserved
 This parameter determines the control mode of this motor.
0: V/F control, the user can design the required V/F ratio. This control mode needs induction motors.
1: Reserved
2: Reserved
3: FOC vector control + Encoder. This control mode needs induction motors.
4: Reserved
5: FOC vector control + Encoder. This control mode needs synchronous motors.
6: Reserved
7: Reserved

Source of operating command
Control mode
VF FOCPG FOCPM
Factory setting: 0
Settings 0: The operating command is controlled by the digital keypad
1: The operating command is controlled by the external terminals.
The STOP button on the keypad is disabled
2: The operating command is controlled by the communication interface.
The STOP button on the keypad is disabled
3: The operating command is controlled by CANopen
 For the operating command, press the PU button to allow the “PU” indicator to be lit. In this case, the RUN,
JOG, and STOP button are enabled.
Motor’s maximum operating frequency
Control mode
VF FOCPG FOCPM
Factory setting: 166.67
Settings 50.00 – 599.00Hz
 Set the maximum operating frequency range of the motor. This setting is corresponding to the maximum
flow for the system.
 When the control mode is FOCPGPM (Pr.01-00=5), the user defined speed display (Pr.00-06) follows the
setting of number of poles of synchronous motor (Pr.01-20) to adjust the motor maximum operating
frequency(Pr.01-02)
 Frequency = Motor’s rotating speed (rpm) x Motor’s number of pole / 120
Motor’s rated frequency
Control mode
VF FOCPG FOCPM
Factory setting: 113.33
Settings 0.00~599.00Hz
 Typically, this setting is configured according to the rated voltage and frequency listed in the specifications
on the motor’s nameplate. If the motor is intended for 60Hz, set this value as 60Hz; if the motor is intended
for 50Hz, set this value as 50Hz.
