Delta VFD220VL43C-J User Manual

Chapter 4 Description of Parameters | VFD-VJ
4-40
Stator resistance (Rs) of the induction motor
Control mode
FOCPG
Factory setting: 0
Rotor resistance (Rr) of the induction motor
Control mode
FOCPG
Factory setting: 0
Settings 0~65.535Ω
Magnetizing inductance (Lm) of the induction motor
Control mode
FOCPG
Factory setting: 0
Total leakage inductance (Lx) of the induction motor
Control mode
FOCPG
Factory setting: 0
Settings 0.0~6553.5mH
Rated current of the synchronous motor
Control mode
FOCPM
Factory setting: 0.00
Settings 0~655.35 Amps
 The user can set the rated current shown on the synchronous motor’s nameplate.
Rated power of the synchronous motor
Control mode
FOCPM
Factory setting: 0.00
Settings 0.00 – 655.35kW
 This parameter sets the rated power of the synchronous motor.
Rated speed of the synchronous motor
Control mode
FOCPM
Factory setting: 1700
Settings 0~65535
 This parameter sets the rated speed of the synchronous motor. It is necessary to refer to the specifications
shown on the motor’s nameplate.
Number of poles of the synchronous motor
Control mode
FOCPM
Factory setting: 8
Settings 2~20
 This parameter sets the number of the synchronous motor’s number of poles (odd number is not allowed).
Inertia of the synchronous motor’s rotor
Control mode
FOCPM
Factory setting: 0.0
Settings 0.0~6553.5 *10
-4
kg.m2
Stator’s phase resistance (Rs) of the synchronous motor
Control mode
FOCPM
Factory setting: 0.000
Settings 0,000~65.535Ω
 Enter the phase resistance of the synchronous motor.
