Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-01-1
01 Basic Parameters This parameter can be set during operation.
Max. Operation Frequency of Motor 1
Max. Operation Frequency of Motor 2
Max. Operation Frequency of Motor 3
Max. Operation Frequency of Motor 4
Factory Setting: 600.0 / 500.0
Settings 0.0~1500.0 Hz
This parameter determines the maximum operation frequency range of drive. This setting is
frequency range corresponding to maximum value of analog input frequency setting signal
(0~10V, 4~20 mA, 0~20 mA，±10V).
Output Frequency of Motor 1
Output Frequency of Motor 2
Output Frequency of Motor 3
Output Frequency of Motor 4
Factory Setting: 600.0 / 500.0
Settings 0.0~1500.0 Hz
This value should be set according to the rated frequency of the motor as indicated on the
motor nameplate. If the motor is 60 Hz, the setting should be 60 Hz. If the motor is 50 Hz, the
setting should be 50 Hz.
Output Voltage of Motor 1
Output Voltage of Motor 2
Output Voltage of Motor 3
Output Voltage of Motor 4
Factory Setting: 220.0 / 440.0
Settings 230 V series: 0.0 V~255.0 V
460 V series: 0.0~510.0 V
This value should be set according to the rated voltage of the motor as indicated on the motor
nameplate. If the motor is 220V, the setting should be 220.0 V. If the motor is 200V, the setting
should be 200.0 V.
A wide variety of motors are sold in the market, but the power system for each country is different.
The economic and convenient way to solve this problem is to install the AC motor drive. The drive
can deal with different voltage and frequency. Besides, it can also exert the original
characteristics and life of the motor.
Mid-point Frequency 1 of Motor 1
Factory Setting: 0.0
Settings 0.0~1500.0 Hz
Mid-point Voltage 1 of Motor 1
Factory Setting: 0.0 / 0.0
Settings 230 V series: 0.0 V~240.0 V
