Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-03-17

Multi-function MO Output by Source of AI Level
Factory Setting: 0
Settings 0: AVI
1: ACI

AI Upper Level 1
Factory Setting: 50
Settings -100 %~100 %

AI Lower Level 2
Factory Setting: 10
Settings -100 %~100 %
 This function requires working with Multi-function Output item “67” Analog signal level achieved.
The MO active when AI input level is higher than Pr. 03-45 AI Upper level. The MO shutoffs when
the AI input is lower that Pr. 03-46 AI Lower level.
 AI Upper level must be higher than AI Lower level

Analog Input Curve Selection
Factory Setting: 0
Settings 0: Regular Curve
1: 3 point curve of AVI (& AI10)
2: 3 point curve of ACI (& AI11)
3: 3 point curve of AVI & ACI (& AI10 & AI11)
(AI10, AI11 is valid when extension card is installed)

ACI Lowest Point
Factory Setting: 4.00
Settings Pr. 03-29 = 1, 0.00~10.00 V
Pr. 03-29 ≠ 1, 0.00~20.00 mA

ACI Proportional Lowest Point
Factory Setting: 0.00
Settings 0.00~100.00 %

ACI Mid-point
Factory Setting: 12.00
Settings 03-29 = 1, 0.00~10.00 V
03-29 ≠ 1, 0.00~20.00 mA

ACI Proportional Mid-point
Factory Setting: 50.00
Settings 0.00~100.00 %

ACI Highest Point
Factory Setting: 20.00
Settings 03-29 = 1, 0.00~10.00 V
03-29 ≠ 1, 0.00~20.00 mA
