Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-03-16
 For Example:
If the value of Pr. 03-30 displays 0002h (Hex), it means AFM is used by PLC.
Bit
AFM 1
10000000
222222 22
7654321 0
Display value
2=1x2 +0x2
=
b
i
t
1
x
2
+
b
i
t
0
x
2
10
10
AFM 2
Weights
0
=No
t
used b
y
PLC
1=Used by PLC

AFM Output Selection
Factory Setting: 0
Settings 0: 0~10 V output
1: 0~20 mA output
2: 4~20 mA output

AFM DC Output Setting Level
Factory Setting: 0.00
Settings 0.00~100.00 %


AFM Filter Output Time
Factory Setting: 0.01
Settings 0.00~20.00 sec.

VR Input Selection
Factory Setting: 1
Settings
0：Disable
1：Frequency command

VR Input Bias
Factory Setting: 0.0
Settings -100~100 %

VR Positive / Negative Bias
Factory Setting: 0
Settings 0: No bias
1: Lower than or equal to bias
2: Greater than or equal to bias
3: The absolute value of the bias voltage while serving as the center
4: Serve bias as the center

VR Gain
Factory Setting: 100.0
Settings -500.0~500.0 %
VR Filter Time
Factory Setting: 0.01
Settings 0~2.00 sec.
