Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-06-11
Fault Code
bit 0 bit 1 bit 2 bit 3 bit 4 bit 5 bit 6
current Volt. OL SYS FBK EXI CE
23: Electronics thermal relay protection 2 (EoL2)
●
24: Motor PTC overheat (oH3)
●
26: Over-torque 1 (ot1)
●
27: Over-torque 2 (ot2)
●
28: Low current (uC)
●
31: Memory read-out error (cF2)
●
33: U-phase current detection error (cd1)
●
34: V-phase current detection error (cd2)
●
35: W-phase current detection error (cd3)
●
36: Clamp current detection error (Hd0)
●
37: Over-current detection error (Hd1)
●
48: Analog current input loss (ACE)
●
49: External fault input (EF)
●
50: Emergency stop (EF1)
●
51: External base block (bb)
●
52: Password error (Pcod)
●
54: Communication error (CE1)
●
55: Communication error (CE2)
●
56: Communication error (CE3)
●
57: Communication error (CE4)
●
58: Communication time-out (CE10)
●
61: Y-connection / ᇞ-connection switch error
(ydc)
●
62: Decel. energy backup error (dEb)
●
72: Channel 1 (S1~DCM) safety loop error
(STL1)
●
76: Safe torque off (STo)
●
77: Channel 2 (S2~DCM) safety loop error
(STL2)
●
78: Internal loop error (STL3)
●
79: U phase over current before run (Aoc)
●
80: V phase over current before run (boc)
●
81: W phase over current before run (coc)
●
82: U phase output phase loss (oPL1)
●
83: V phase output phase loss (oPL2)
●
84: W phase output phase loss (oPL3)
●
87: Drive over load in low frequency (oL3)
●
101: CANopen software disconnect 1 (CGdE)
●
