Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-06-12
Fault Code
bit 0 bit 1 bit 2 bit 3 bit 4 bit 5 bit 6
current Volt. OL SYS FBK EXI CE
102: CANopen software disconnect 2 (CHbE)
●
104: CANopen hardware disconnect (CbFE)
●
105: CANopen index setting error (CIdE)
●
106: CANopen station number setting error
(CAdE)
●
107: CANopen memory error (CFrE)
●
121: Internal communication error (CP20)
●
123: Internal communication error (CP22)
●
124: Internal communication error (CP30)
●
126: Internal communication error (CP32)
●
127: Software version error (CP33)
●
128: Over-torque 3 (ot3)
●
129: Over-torque 4 (ot4)
●
134: Electronics thermal relay 3 protection
(EoL3)
●
135: Electronics thermal relay 4 protection
(EoL4)
●
140: GFF detected when power on (Hd6)
●
141: GFF occurs before run (b4GFF)
●
145: Model identification error (MErr)
●
PTC Detection Selection
Factory Setting: 0
Settings 0: Warn and keep operating
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning
This is the operating mode of a drive after Pr. 06-29 is set to define PTC detection.
PTC Level
Factory Setting: 50.0
Settings 0.0~100.0 %
It needs to set AVI / ACI analog input function Pr. 03-00~03-02 to 6 [Positive temperature
coefficient (PTC) thermistor input value)].
It is used to set the PTC level, and the corresponding value for 100 % is analog input max. value.
Frequency Command for Malfunction
Factory Setting: Read only
Settings 0.0~1500.0 Hz
When malfunction occurs, user can check current frequency command. If it happens again, it will
overwrite the previous record.
