Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-06-13
Output Frequency at Malfunction
Factory Setting: Read only
Settings 0.0~1500.0 Hz
When malfunction occurs, user can check current output frequency. If it happens again, it will
overwrite the previous record.
Output Voltage at Malfunction
Factory Setting: Read only
Settings 0.0~6553.5 V
When malfunction occurs, user can check current output voltage. If it happens again, it will
overwrite the previous record.
DC Voltage at Malfunction
Factory Setting: Read only
Settings 0.0~6553.5 V
When malfunction occurs, user can check current DC voltage. If it happens again, it will overwrite
the previous record.
Output Current at Malfunction
Factory Setting: Read only
Settings 0.00~655.35 Amp
When malfunction occurs, user can check current output current. If it happens again, it will
overwrite the previous record.
IGBT Temperature at Malfunction
Factory Setting: Read only
Settings 0.0~6553.5
o
C
When malfunction occurs, user can check current IGBT temperature. If it happens again, it will
overwrite the previous record.
Capacitance Temperature at Malfunction
Factory Setting: Read only
Settings -0.0~6553.5
o
C
When malfunction occurs, user can check current capacitance temperature. If it happens again, it
will overwrite the previous record.
Motor Speed in rpm at Malfunction
Factory Setting: Read only
Settings 0~65535 rpm
When malfunction occurs, user can check current motor speed in rpm. If it happens again, it will
overwrite the previous record.
Status of Multi-function Input Terminal at Malfunction
Factory Setting: Read only
Settings 0000h~FFFFh
