Chapter 15 CANopen OverviewMS300 (High Speed Model)
15-18
Index Sub Definition
Factory
Setting
R/W Size Note
1D
Display PLC register D1043
data
0 R U16
1E
1F
User page displays the value
in physical measure
0 R U16
20
Output Value of Pr. 00-05
0 R U16
21
22
23
Fan speed of the drive
0 R U16
24
Control mode of the drive 0:
speed mode 1: torque mode
0 R U16
25
Carrier frequency of the drive
0 R U16
26 Reserved
27 Status of the drive
28
29 Reserved
2A KWH display
2B PG2 pulse input in low word
2C PG2 pulse input in high word
2D
2E
2F
30
31
CANopen Remote IO mapping
Index Sub R/W Definition
2026H
01h R Each bit corresponds to the different input terminals
02h R Each bit corresponds to the different input terminals
03h~40h R Reserved
41h RW Each bit corresponds to the different output terminals
42h~60h R Reserved
61h R AVI (%)
62h R ACI (%)
63h R Reserved
64h~A0h R Reserved
A1h RW
AFM1 (%)
A2h RW
AFM2 (%)
Index
2026-01
Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 8 Bit 9 Bit 10 Bit 11 Bit 12 Bit 13 Bit 14 Bit 15
1 FWD REV MI1 MI2 MI3 MI4 MI5 MI6 MI7 MI8
1: Control broad I/O (Standard)
2: Add external card, EMM-D33A
Index
2026-41
Bit 0 Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 8 Bit 9 Bit 10 Bit 11 Bit 12 Bit 13 Bit 14 Bit 15
1 RY Reserved Reserved MO1 MO2
1: Control broad I/O (Standard)
