Chapter 16 PLC Function ApplicationsMS300 (High Speed Model)
16-7
16-3-2 I/O device explanation
Input devices:
Serial
No.
X0 X1 X2 X3 X4 X5 X6 X7 X10 X11 X12 X13 X14 X15 X16 X17
1
MI1 MI2 MI3 MI4 MI5 MI6 MI7
Output devices:
Serial
No.
Y0 Y1 Y2 Y3 Y4 Y5 Y6 Y7 Y10 Y11 Y12 Y13 Y14 Y15 Y16 Y17
1
RY MO1 MO2
16-3-3 Installation WPLSoft
See Delta's website for WPLSoft editing software:
http://www.delta.com.tw/product/em/download/download_main.asp?act=3&pid=3&cid=1&tpid=3
16-3-4 Program writing
After completing installation, the WPLSoft program will be installed in the designated subfolder
"C:\Program Files\Delta Industrial Automation\WPLSoft x.xx." The editing software can now be run
by clicking on the WPL icon using the mouse.
