Chapter 16 PLC Function ApplicationsMS300 (High Speed Model)
16-32
16-5-4 PLC Communication address
Device Range Type Address (Hex)
X 00~17 (Octal) bit 0400~040FF
Y 00~17 (Octal) bit 0500~050F
T 00~79 bit/word 0600~064F
M 000~799 bit 0800~0B1F
M 1000~1279 bit 0BE8~0CFF
C 0~39 bit/word 0E00~0E27
D 00~199 word 1000~10C7
D 1000~ 1219 word 13E8~ 14C3
Command code that can be used
Function Code Description of Function Function target
H1
Coil status read Y,M,T,C
H2
Input status read X,Y,M,T,C
H3
Read single unit of data T,C,D
H5
Compulsory single coil status change Y,M,T,C
H6
Write single unit of data T,C,D
HF
Compulsory multiple coil status change Y,M,T,C
H10
Write multiple units of data T,C,D
NOTE
When PLC functions have been activated, the MS300 can match PLC and drive parameters; this method employs different
addresses, drives (default station number is 1, PLC sets station number as 2)
