Chapter 16 PLC Function ApplicationsMS300 (High Speed Model)
16-39
Command Function
RST
Clear contact or register
Operand
X0~X17 Y0~Y17 M0~M799 T0~159 C0~C79 D0~D399
－
    
When the RST command is driven, the action of the designated element will be as
follows:
Element Mode
Y, M Both coil and contact will be set as Off.
T, C
The current timing or count value will be set as 0, and both the coil
and contact ill be set as Off.
D The content value will be set as 0.
If the RST command has not been executed, the status of the designated element will
remain unchanged.
Ladder diagram:
X0
Y5
RST
Command code: Description:
LD X0
Load Contact A of X0
RST Y5
Clear contact or
register
Command Function
TMR
16-bit timer
Operand
T-K
T0~T159，K0~K32,767
T-D
T0~T159，D0~D399
When the TMR command is executed, the designated timer coil will be electrified, and
the timer will begin timing. The contact's action will be as follows when the timing
value reaches the designated set value (timing value >= set value):
NO (Normally Open) contact Closed
NC (Normally Close) contact Open
If the RST command has not been executed, the status of the designated element will
remain unchanged.
Ladder diagram:
X0
T5
TMR
K1000
Command code: Description:
LD X0
Load Contact
A of X0
TMR
T5 K1000
T5 timer
Set value as K1000
Command Function
CNT
16-bit counter
Operand
C-K
C0~C79，K0~K32,767
C-D
C0~C79，D0~D399
When the CNT command is executed from Off→On, this indicates that the designated
counter coil goes from no power → electrified, and 1 will be added to the counter's
count value; when the count reaches the designated value (count value = set value),
the contact will have the following action:
NO (Normally Open) contact Closed
NC (Normally Close) contact Open
After the count value has been reached, the contact and count value will both remain
unchanged even if there is continued count pulse input. Please use the RST
command if you wish to restart or clear the count.
Ladder diagram:
X0
C2
CNT K100
Command code: Description:
LD X0
Load Contact
A of X0
CNT C2 K100
C2counter
Set value as K100
