Chapter 16 PLC Function ApplicationsMS300 (High Speed Model)
16-46
Classification API
Command code
P
command
Function
STEPS
16 bit 32 bit 16 bit 32 bit
Floating point
operation
136 – DSINH

Binary floating point number
SINH operation
– 9
137 – DCOSH

Binary floating point number
COSH operation
– 9
138 – DTANH

Binary floating point number
TANH operation
– 9
Calendar
160 TCMP –

Compare calendar data 11 –
161 TZCP –

Compare calendar data range 9 –
162 TADD –

Calendar data addition 7 –
163 TSUB –

Calendar data subtraction 7 –
166 TRD –

Calendar data read 3 –
GRAY code
170 GRY DGRY

BIN→GRY code
transformation
5 9
171 GBIN DGBIN

GRY code →BIN
transformation
5 9
Contact form
logical
operation
215 LD& DLD& -
Contact form logical operation
LD #
5 9
216 LD| DLD| -
Contact form logical operation
LD #
5 9
217 LD^ DLD^ -
Contact form logical operation
LD #
5 9
218 AND& DAND& -
Contact form logical operation
AND #
5 9
219 ANDl DANDl -
Contact form logical operation
AND #
5 9
220 AND^ DAND^ -
Contact form logical operation
AND #
5 9
221 OR& DOR& -
Contact form logical operation
OR #
5 9
222 OR| DOR| -
Contact form logical operation
OR #
5 9
223 OR^ DOR^ -
Contact form logical operation
OR #
5 9
Contact form
compare
command
224
LD＝ DLD＝
- Contact form compare LD* 5 9
225
LD＞ DLD＞
- Contact form compare LD* 5 9
226
LD＜ DLD＜
- Contact form compare LD* 5 9
228
LD＜＞ DLD＜＞
- Contact form compare LD* 5 9
229
LD＜＝ DLD＜＝
- Contact form compare LD* 5 9
230
LD＞＝ DLD＞＝
- Contact form compare LD* 5 9
232
AND＝ DAND＝
- Contact form compare AND* 5 9
233
AND＞ DAND＞
- Contact form compare AND* 5 9
234
AND＜ DAND＜
- Contact form compare AND* 5 9
236
AND＜＞ DAND＜＞
- Contact form compare AND* 5 9
237
AND＜＝ DAND＜＝
- Contact form compare AND* 5 9
238
AND＞＝ DAND＞＝
- Contact form compare AND* 5 9
240
OR＝ DOR＝
- Contact form compare OR* 5 9
241
OR＞ DOR＞
- Contact form compare OR* 5 9
242
OR＜ DOR＜
- Contact form compare OR* 5 9
244
OR＜＞ DOR＜＞
- Contact form compare OR* 5 9
245
OR＜＝ DOR＜＝
- Contact form compare OR* 5 9
246
OR＞＝ DOR＞＝
- Contact form compare OR* 5 9
