Chapter 9 Specification MS300 (High Speed Model)
9-5
460V series_3-phase without built-in filter
Model VFD_ _ _ _ _ _ _
ANSHA
ENSHA
13AMS43 17AMS43 25AMS43 32AMS43 38AMS43 45AMS43
Applicable Motor Output (kW) 5.5 7.5 11 15 18.5 22
Applicable Motor Output (hp) 7.5 10 15 20 25 30
Output
Heavy
duty
Rated Output Capacity (kVA) 9.9 13 19.1 24.4 29 34.3
Rated Output Current (A) 13 17 25 32 38 45
Carrier Frequency (kHz) 2~15 (default 6)
Input
Rated Input
Current (A)
Heavy Duty 14.3 18.7 27.5 35.2 41.8 49.5
Rated Voltage / Frequency 3-phase AC 380V~480VAC (-15% ~ +10%) / 50/60Hz
Mains Input Voltage Range (VAC) 342~528
Mains Frequency Range (Hz) 47~63
Frame D1 E1 F1
AC Drive Weight (kg) 2.91 5.15 8.50
Cooling Method Fan cooling with fan kit
EMC Filter Optional
IP Rating
VFD_ _ _ _ _ _ _ ANSHA : IP20
VFD_ _ _ _ _ _ _ ENSHA : IP40*
460V series_3-phase with built-in filter
Model VFD_ _ _ _ _ _ _ AFSHA 13AMS43 17AMS43 25AMS43 32AMS43 38AMS43 45AMS43
Applicable Motor Output (kW) 5.5 7.5 11 15 18.5 22
Applicable Motor Output (hp) 7.5 10 15 20 25 30
Output
Heavy
duty
Rated Output Capacity (kVA) 9.9 13 19.1 24.4 29 34.3
Rated Output Current (A) 13 17 25 32 38 45
Carrier Frequency (kHz) 2~15 (default 6)
Input
Rated Input
Current (A)
Heavy Duty 14.3 18.7 27.5 35.2 41.8 49.5
Rated Voltage / Frequency 3-phase AC 380V~480VAC (-15% ~ +10%) / 50/60Hz
Mains Input Voltage Range (VAC) 342~528
Mains Frequency Range (Hz) 47~63
Frame D2 E2 F2
AC Drive Weight (kg) 2.07 3.97 6.25
Cooling Method Fan cooling with fan kit
EMC Filter Built-in
IP Rating IP20
NOTE
IP40*: The IP rating of wiring area (main circuit terminals and control terminals, frame B/C/D/E/F) and the vent near capacitor (frame C/D/E/F)
is IP20.
The value of the carrier frequency is a factory setting. To increase the carrier frequency, the current needs to be decreased. See derating
curve diagram of Pr. 06-55 for more information.
When a load is a shock or impact load, use a higher level model.
