Chapter 9 Specification MS300 (High Speed Model)
9-6
General Specifications
Control
Characteristics
Control Method V/F
Applied Motor IM (Induction Motor)
Max. Output
Frequency
0.0~1500.0 Hz
Overload
Capability
Heavy duty: 150% 60s, 200% 3s
Frequency
Setting Signal
0~+10V / -10V~+10V
4~20 mA / 0~+10V
1 channel pulse input (33kHz), 1 channel pulse output (33 KHz)
Main Function
Multi-motor switching (4 independent motor parameters), Fast Run, DEB
function, Momentary power loss ride thru, Speed search, Over-torque detection,
16-step speed (including main speed), Accel. / decel. time switch, S-curve
accel./ decal., 3-wire sequence, JOG frequency, Frequency upper/lower limit
settings, DC injection braking at start/stop, Built-in PLC (2000 steps)
Application
Macro
Built-in application parameter groups(selected by industry) and user-defined
application parameter groups.
Protection
Characteristics
Motor Protection Over-current, Over-voltage, Over-temperature, Phase loss
Stall Prevention
Stall prevention during acceleration, deceleration and running (independent
settings)
Accessory
Communication
Cards
DeviceNet, Ethernet/IP, Profibus DP, Modbus TCP, CANopen
External DC
Power Supply
EMM-BPS01 (DC 24V power supply card )
Certifications UL, CE, C-Tick, TÜV (SIL 2), RoHS, REACH
[Note 1] Control accuracy may vary depending on the environment, application conditions, different motors or encoder.
For details, please contact our company or your local distributor.
