Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-23
Pr. Explanation Settings
Factory
Setting
135: Electronics thermal relay 4 protection (EoL4)
140: GFF detected when power on (Hd6)
141: GFF occurs before run (b4GFF)
145: Model identification error (MErr)

06-23 Fault output option 1 0~65535 (refer to bit table for fault code) 0

06-24 Fault output option 2 0~65535 (refer to bit table for fault code) 0

06-25 Fault output option 3 0~65535 (refer to bit table for fault code) 0

06-26 Fault output option 4 0~65535 (refer to bit table for fault code) 0

06-27
Electronic thermal relay selection 2
(motor 2)
0: Inverter motor (with external forced cooling)
1: Standard motor (motor with fan on the shaft)
2: Disabled
2

06-28
Electronic thermal relay action time
2 (motor 2)
30.0~600.0 sec.
60.0

06-29 PTC detection selection
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning
0

06-30 PTC level
0.0 ~100.0 %
50.0
06-31
Frequency command for
malfunction
0.0~1500.0 Hz
Read
only
06-32 Output frequency at malfunction 0.0~1500.0 Hz
Read
only
06-33 Output voltage at malfunction
0.0~6553.5 V
Read
only
06-34 DC voltage at malfunction
0.0~6553.5 V
Read
only
06-35 Output current at malfunction 0.00~655.35 Amp
Read
only
06-36
IGBT temperature at malfunction
0.0~6553.5
o
C
Read
only
06-37
Capacitance temperature at
malfunction
0.0~6553.5
o
C
Read
only
06-38 Motor speed in rpm at malfunction 0~65535 rpm
Read
only
06-40
Status of multi-function input
terminal at malfunction
0000h~FFFFh
Read
only
06-41
Status of multi-function output
terminal at malfunction
0000h~FFFFh
Read
only
