Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-24
Pr. Explanation Settings
Factory
Setting
06-42 Drive’s status at malfunction 0000h~FFFFh
Read
only
06-44 STO latch selection
0: STO Latch
1: STO No Latch
0
06-45
Treatment to output phase loss
detection (OPHL)
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning
3
06-46 Detection time of output phase loss 0.000~65.535 sec.
0.500
06-47
Current detection level of output
phase loss
0.00~100.00 % 1.00
06-48
DC Brake time of output phase loss
0.000~65.535 sec.
0.000
06-49 LvX auto reset
0: Disabled
1: Enabled
0
06-53
Treatment for the detected input
phase Loss (OrP)
0: Warn and ramp to stop
1: Warn and coast to stop
0
06-55 Derating protection
0: Constant rated current and limit carrier wave by
load current and temperature
1: Constant carrier frequency and limit load current
by setting carrier wave
2: Constant rated current (same as setting 0), but
close current limit
0
06-56 PT100 voltage level 1 0.000~10.000 V 5.000
06-57 PT100 voltage level 2
0.000~10.000 V
7.000
06-58 PT100 level 1 frequency protect
0.0~1500.0 Hz
0.0
06-59
Delay Time of Activating PT100
Level 1 Frequency Protection
0~6000 sec. 60
06-60
Software detection GFF current
level
0.0~6553.5 %
60.0
06-61
Software detection GFF filter time 0.00~655.35 sec.
0.10
06-63
Operation time of fault record 1
(Day)
0~65535 days
Read
only
06-64
Operation time of fault record 1
(Min.)
0~1439 min.
Read
only
06-65
Operation time of fault record 2
(Day)
0~65535 days
Read
only
06-66
Operation time of fault record 2
(Min.)
0~1439 min.
Read
only
