Deltronic Security TT-2000 Ticket Eater - Diagnostic Leds

TT-2000 Ticket Eater™ by Deltronic Labs February 2013
20
Diagnostic LEDs
The Ticket Eater has several diagnostic LEDs:
Location
Color
Indicates
Status
Logic Board
Red
+5 V Power
Normally On
Logic Board
Green
+12 V Power
Normally On
Motor Drive Board
Red
Motor Control Signal
from Logic Board
Motor should be on when it is on
HO-1000 Rev. 1-4 D1
Red
Ticket detected
Off when front sensor sees ticket
HO-1000 Rev. 1-4 D2
Red
Ticket detected
On when middle sensor sees ticket
HO-1000 Rev. 1-4 D3
Red
Ticket Jam if off when
don’t have tickets
Off rear sensors see ticket
BCR-1000 Rev. 1-4 Front
Red
Ticket detected
Off when front sensor sees ticket
BCR-1000 Rev. 1-4 Rear
Red
Ticket Jam if off when
don’t have tickets
Off when rear sensors see ticket
HO-1000 Rev. 5 LED 1
Red
Ticket detected
On when middle front sensor sees ticket
HO-1000 Rev. 5 LED 2
Red
Ticket detected
On when right rear sensor sees ticket
HO-1000 Rev. 5 LED 3
Red
Ticket detected
On when left rear sensor sees ticket
HO-1000 Rev. 5 LED 4
Red
Ticket detected
Off when front sensor sees ticket
HO-1000 Rev. 5 LED 5
Red
Cheating
Flashes On when error is detected
HO-1000 Rev. 5 LED 6
Red
Ticket detected
On when middle rear sensor sees ticket
BCR-1000 Rev. 5 LED 1
Red
Cheating
Flashes On when error is detected
BCR-1000 Rev. 5 LED 2
Red
Ticket detected
Off when front sensor sees ticket
BCR-1000 Rev. 5 LED 3
Red
Ticket detected
On when middle sensor sees a bar in
the barcode
BCR-1000 Rev. 5 LED 4
Red
Ticket detected
On when middle rear sensor sees ticket
BCR-1000 Rev. 5 LED 5
Red
Ticket detected
On when left rear sensor sees ticket
BCR-1000 Rev. 5 LED 6
Red
Ticket detected
On when right rear sensor sees ticket
