TT-2000 Ticket Eater™ by Deltronic Labs February 2013
9
Group 99 3
Option Number
Values
30
0 = BCR-1000
1 = HO-1000
2 = BCR as HO (see NOTE)
3 = DS-2000
4 = BCR-2000
5 = HO-2000
31
4 to 5
32
0 = No, 1 = Yes
33
0 = 0% (most strict)
1 = 25%
2 = 50%
3 = 75%
4 = 100% (rejects nothing)
34
1 to 99
35
0 to 99
36
4, 5, 8 (see page 3)
37
0 = 60 Hz, 1 = 50 Hz
NOTE: BCR sensor boards are used to count barcoded tickets. HO sensor boards
are used to count holes-only tickets. Barcode sensor boards can be used to count
holes-only tickets, but there is NO CHEAT DETECTION when used this way. This
should only be done in an emergency situation. Some barcode sensor boards can be
configured by means of jumpers on the board to work as a holes-only sensor board.
In this case choose HO. In this case you will have cheat detection.
Group 99 4
Option Number
Values
41
0 to 99
42
0 to 99
43
0 to 99
44
0 to 99
45
0 to 99
46
0 to 99
47
0 to 99
48
0 to 99
Group 99 4 sets the points value for barcoded tickets. When using barcoded tickets, the
Ticket Eater accepts only tickets that have the correct barcode. To do this it must first
learn the barcode pattern on the tickets. It can learn 8 different barcodes, each with its
own point value.
To teach the Ticket Eater a barcode:
1. Go to one of the option numbers in group 99 4.
2. Use the black and red buttons to adjust the point value.
3. Feed the Ticket Eater a strip of seven tickets.
4. After reading the tickets the ticket eater will display a series of numbers which
represent the barcode pattern. (If these numbers are all zeros, the reading failed.)
