Demtech Pro-Wedge VM-20 - Appendix B, Pro-Wedge Speed Setting Versus Travel Rate Chart

Rev. F, December 2020
Page 22 Pro-Wedge VM-20 Operator’s Manual
9.2 Appendix B, Pro-Wedge Speed Setting Versus Travel Rate Chart
Speed setting versus actual travel speed (FEET PER MINUTE)
Speed setting versus actual travel speed (METERS PER MINUTE)
Setting
Low Gear
High Gear
999
18
32
950
16
29
900
15
27.5
850
14
26
800
13
24.5
750
12.5
22.5
700
12
21
650
11
19.5
600
10
18
550
9.5
16.5
500
8.5
15
450
8
13.5
400
7
12
350
6
10.5
300
5.5
9
250
4.5
7.5
200
3
6
150
2
4
100
1
3
Setting Low Gear High Gear
999
18
32
950
16
29
900
15
27.5
850
14
26
800
13
24.5
750
12.5
22.5
700
12
21
650
11
19.5
600
10
18
550
9.5
16.5
500
8.5
15
450
8
13.5
400
7
12
350
6
10.5
300
5.5
9
250
4.5
7.5
200
3
6
150
2
4
100
1
3
Setting Low Gear High Gear
999
18
32
950
16
29
900
15
27.5
850
14
26
800
13
24.5
750
12.5
22.5
700
12
21
650
11
19.5
600
10
18
550
9.5
16.5
500
8.5
15
450
8
13.5
400
7
12
350
6
10.5
300
5.5
9
250
4.5
7.5
200
3
6
150
2
4
100
1
3
Setting
Low Gear
High Gear
999
5.4
9.6
950
4.8
8.8
900
4.5
8.3
850
4.2
7.9
800
3.9
7.4
750
3.8
6.8
700
3.6
6.4
650
3.3
5.9
600
3
4.5
550
2.9
5
500
2.6
4.5
450
2.4
4
400
2.1
3.6
350
1.8
3.1
300
1.7
2.7
250
1.4
2.3
200
0.9
1.8
150
0.6
1.2
100
0.3
0.9
Setting Low Gear High Gear
999
5.4
9.6
950
4.8
8.8
900
4.5
8.3
850
4.2
7.9
800
3.9
7.4
750
3.8
6.8
700
3.6
6.4
650
3.3
5.9
600
3
4.5
550
2.9
5
500
2.6
4.5
450
2.4
4
400
2.1
3.6
350
1.8
3.1
300
1.7
2.7
250
1.4
2.3
200
0.9
1.8
150
0.6
1.2
100
0.3
0.9
Setting Low Gear High Gear
999
5.4
9.6
950
4.8
8.8
900
4.5
8.3
850
4.2
7.9
800
3.9
7.4
750
3.8
6.8
700
3.6
6.4
650
3.3
5.9
600
3
4.5
550
2.9
5
500
2.6
4.5
450
2.4
4
400
2.1
3.6
350
1.8
3.1
300
1.7
2.7
250
1.4
2.3
200
0.9
1.8
150
0.6
1.2
100
0.3
0.9
