Rev. F, December 2020
Pro-Wedge VM-20 Operator’s Manual Page iii
Table of Contents
1 SAFETY PRECAUTIONS………………………………………………….PAGE 1
2 GENERAL SAFETY & MAINTENANCE INFORMATION……………PAGE 2
2.1
Intended Use…………………………………………………………Page 2
2.2
Maintenance…………………………………………………………Page 2
3 GENERAL PRODUCT DATA……………………………………………..PAGE 3
4 OPERATING ENVIRONMENT…………………………………………...PAGE 3
5 SITE PREPARATION……………………………………………………....PAGE 3
6 UNPACKING & INSTALLATION INSTRUCTIONS…………………...PAGE 4
6.1
Unpacking and Preparation………………………………………….Page 4
6.2
Electrical Plug Connection…………………………………………..Page 5
6.3
Generator Recommendations………………………………………..Page 5
6.4
Accessories………………………………………………………….Page 6
7 MATERIAL SET-UP……………………………………………………….PAGE 6
7.1
Set-up Nip Pressure Adjustment…………………………………….Page 7
7.2
Set-up Upper Contour Roller Configurations……………………...Page 9
7.3
Set-up Lower Contour Roller Adjustment…………………………Page 13
8 WELDING PROCEDURE………………………………………………...PAGE 16
8.1
Power Up…………………………………………………………...Page 16
8.2
Setting Wedge Temperature………………………………………..Page 17
