Demtech Pro-Wedge VM-20 - Pro-Wedge Box Wiring Schematic (Parts List)

Rev. F, December 2020
Page 26 Pro-Wedge VM-20 Operator’s Manual
PARTS LIST
ITEM
PART NO
DESCRIPTION
QTY
1
100-400
MOTOR, DRIVE, MODEL 0161, MODIFIED
1
2
100-450
SWITCH, ON/OFF, MOTOR, 2 POLE
1
3
100-450.1
TOGGLE SWITCH, ON/OFF (POWER), 4 POLE
1
4
100-472
HOUSING, CONNECTOR, 6 PIN, FEMALE
1
5
100-475/A
ASSEMBLY, POWER CORD, 120V
1
6
NS-HARDWARE
TERMINAL, QUICK-DISCONNECT, 16-14 AWG FEMALE, FULLY INSULATED, BLUE
1
7
NS-HARDWARE
TERMINAL, QUICK-DISCONNECT, 16-14 AWG MALE, FULLY INSULATED, BLUE
1
8
NS-HARDWARE
MATE-N-LOK, PIN, 16 AWG, TIN
6
9
NS-HARDWARE
TUBING, HEAT SHRINK, FLEXIBLE, POLYOLEFIN
6
9.6 Pro-Wedge Box Wiring Schematic (Parts List)
