Demtech Pro-Wedge VM-20 - Pro-Wedge Lid Wiring Schematic (Parts List)

Rev. F, December 2020
Page 24 Pro-Wedge VM-20 Operator’s Manual
PARTS LIST
ITEM
PART NO
DESCRIPTION
QTY
1
100-415
CONTROL BOARD, MOTOR, 110V
1
2
100-160A/A
ASSEMBLY, 1 3/4" (45mm) COPPER, DUAL TRACK, 110V W/ HEATERS AND T.C.
1
3
100-416
POTENTIOMETER, PUSH BUTTON, MOTOR
1
4
100-426
CONTROLLER, TEMPERATURE, EZ-ZONE
1
5
100-431
RELAY, SOLID STATE, 25A, 3-32VDC, 240V
1
6
100-435
ASSEMBLY, THERMOCOUPLE
1
7
100-456
FUSE, 20 AMP (110V MODEL)
2
8
100-457
FUSE, 1.5 AMP
1
9
100-435
ASSEMBLY, THERMOCOUPLE
1
10
100-471
HOUSING, CONNECTOR, 6 PIN, MALE
1
11
NS-HARDWARE
FERRULE, CRIMP, 12 AWG, 10MM PIN LENGTH
13
12
NS-HARDWARE
MATE-N-LOK, SOCKET, 20-14 AWG, TIN
6
13
NS-HARDWARE
TERMINAL, RING, 16-14 AWG, 3/6" STUD
4
14
NS-HARDWARE
TERMINAL, QUICK-DISCONNECT, 12-10 AWG FEMALE, FULLY INSULATED, YELLOW
2
15
NS-HARDWARE
TERMINAL, QUICK-DISCONNECT, 16-14 AWG FEMALE, FULLY INSULATED, BLUE
1
16
NS-HARDWARE
TUBING, HEAT SHRINK, FLEXIBLE, POLYOLEFIN
11
9.4 Pro-Wedge Lid Wiring Schematic (Parts List)
