Denon AVR-1311 Service Manual

36
YES
YES
YES
(19) Check xtal oscillator.
Is there 28.6363MHz oscillation of X101?
(20) Check RESET.
Is RESET waveform confi rmed in IC11 (97pin), when power is
turned on? (If continued to "H" or " L", proceed to "NO".)
HDMI output circuitry is defective (IC11 and surrounding circuitry).
(21) Check control signal(I2C).
Is waveform confi rmed in IC11 78pin(SDATA)/79pin(SCL). (If not
continued to " L", proceed to "YES".)
The X101 or IC11 is defective.
The RESET pattern or IC11 is defective.
The SDATA/SCL line pattern is defective.
NO
NO
NO

Denon AVR-1311 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
3D Technology	Yes
HDMI Pass-Through	Yes
Frequency Response	10 Hz - 100 kHz
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS-HD Master Audio
Tuner Type	FM/AM
Speaker Impedance	6 - 16 ohms
Weight	8.3 kg
