Denon AVR-1311 Service Manual

8
1. FRONT PANEL ASSY
(1) Remove the screws.
(2) Cut the wire clamp band, then disconnect the connector wires and FFC cable. Remove the screws.
(3) Remove the screws.
TOP

COVER
FRONT PANEL ASSY
→
Proceeding :
View from bottom
CN209
CN71
FFC cable
CN44
cut
cut
FRONT PANEL ASSY
WIRE SUPPORT UNIT
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in FRONT PANEL ASSY.
