Denon AVR-1311 Service Manual

91
Ref. No. Part No. Part Name Remarks Q'ty New
CN207 nsp LOCKINGTYPE STRAIGHTWAFER 2mm CJP05GI236ZW
CN208 nsp WAFER STRAIGHT CJP05GA19ZY
CN209 nsp WAFER ANGLE(2.5mm) CJP05GB03ZY
z
F201 943652000620S FUSE(0.1A 372SERIES/TR5) CBA2D0100A3EYT
FL201 943172010110S VFD HCA-18SM01T CFLHCA18SM01T *
GND21,22 nsp PCB BRACKET CMD1A569
JK201 90M-YT004310R JACK BOARD(3P) CJJ4S041Z
JK202 943643010130S JACK CJJ2E020Z *
JK204 943643010140S JACK HEADPHONE(3.5mm GOLD) CJJ2E028Z *
L201-206 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
LUG21 nsp WIRE ASS'Y(1P) CWE8102080RV
LUG22 nsp WIRE ASS'Y CWE8202100RV
LUG24 nsp WIRE ASS'Y CWE8102100RV
LUG25 nsp WIRE ASS'Y CWE8102150RV
LUG26 nsp WIRE ASS'Y(1P) CWE8202080RV
RC201 943262010290S REMOCON SENSOR CRVKSM603TH5B
SW201-218 00D9430004402 TACT SW CST1A012ZT

Denon AVR-1311 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
3D Technology	Yes
HDMI Pass-Through	Yes
Frequency Response	10 Hz - 100 kHz
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS-HD Master Audio
Tuner Type	FM/AM
Speaker Impedance	6 - 16 ohms
Weight	8.3 kg
