Denon AVR-1311 Service Manual

93
Ref. No. Part No. Part Name Remarks Q'ty New
ZD41 943202010070S DIODE ZJ12B CVDZJ12BT
ZD48 943202010080S DIODE ZJ5.1B CVDZJ5.1BT
ZD49 90M-HD302440R DIODE ZJ4.7B CVDZJ4.7BT
ZD51-60 90M-HD302390R DIODE ZJ3.3B CVDZJ3.3BT
RESISTORS GROUP
R494-501 nsp METAL OXIDE FILM RES(4.7KOHM 5% 1W) KRG1SANJ4R7RT
R502 nsp METAL OXID EFILM RES(120OHM 1W J) KRG1SANJ121RT
R505-514 nsp METAL OXIDE FILMRES 2W KRG2SANJR47RT
R515 nsp METAL OXIDEFILM RES(10OHM 1W J) KRG1SANJ100RT
R516-520 nsp METAL OXIDE FILMRES 2W KRG2SANJR47RT
R527-531 nsp METAL OXIDEFILM RES(10OHM 1W J) KRG1SANJ100RT
R532 nsp METAL OXIDE FILMRES 2W KRG2SANJR47RT
R533-537 nsp METAL OXID EFILM RES(2.2KOHM 1W J) KRG1SANJ222RT
R538 nsp METAL OXIDEFILM RES(10OHM 1W J) KRG1SANJ100RT
R539-542 nsp METAL OXID EFILM RES(1.2KOHM 1W) CRG1SANJ122RT
R543-546 nsp METAL OXID EFILM RES(47OHM 1W J) KRG1SANJ470RT
R547-554 nsp METAL OXID EFILM RES CRG1SANJ562RT
R559 nsp METAL OXID EFILM RES(2.2KOHM 1W J) KRG1SANJ222RT
R563 nsp METAL OXIDE FILM RES(4.7KOHM 5% 1W) KRG1SANJ4R7RT
R564 nsp METAL OXIDE FILM RES(100KOHM 5% 1W) KRG1SANJ101RT
R577 nsp METAL OXIDEFILM RES(10OHM 1W J) KRG1SANJ100RT
R616 nsp METAL OXID EFILM RES(1.2KOHM 1W) CRG1SANJ122RT
R618 nsp METAL OXID EFILM RES(47OHM 1W J) KRG1SANJ470RT
R619 nsp METAL OXIDEFILM RES(10OHM 1W J) KRG1SANJ100RT
R621 nsp METAL OXIDEFILM RES(10OHM 1W J) KRG1SANJ100RT
R625-628 nsp METAL OXIDE FILMRES 2W KRG2SANJR47RT
nsp METAL OXID EFILM RES CRG1SANJ562RT
R632 nsp METAL OXID EFILM RES CRG1SANJ562RT
R634,635 nsp METAL OXIDE FILM RES(4.7KOHM 5% 1W) KRG1SANJ4R7RT
VR41-45 nsp SEMI FIXED RES(1K BCURVE) CVN12A102B03T
CAPACITORS GROUP
C403 943134010660S ELECT CAP 470UF 6.3V CCEA0JH471T
C404-407 nsp MYLAR CAP 2200PF 100V J HCQI1H222JZT
C408 943134010680S ELECT CAP 47UF 50V CCEA1HH470T
C409 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C410 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C411,412 nsp CERAMIC CAP 100PF 50V KB CCKT1H101KB
C413 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C414 nsp CERAMIC CAP 100PF 50V KB CCKT1H101KB
C415 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C416-418 nsp SEMICONDUCTOR CAP 0.1UF 50V ZF CCFT1H104ZF
C419,420 nsp MYLAR CAP 0.01UF 100V J 1311E2 HCQI1H103JZT
C419,420 nsp MYLAR CAP 1000PF 100V J MYLAR
1311E1C,391E3,
391E3B,391EA
HCQI1H102JZT
C421 nsp CERAMIC CAP 470PF 50V KB CCKT1H471KB
C422 nsp CERAMIC CAP 100PF 50V KB CCKT1H101KB
s

Denon AVR-1311 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08%
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Preset Station Qty	56
HDMI Switching	Yes
3D Technology	Yes
HDMI Pass-Through	Yes
Frequency Response	10 Hz - 100 kHz
Power Output	75 W per channel (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
Dolby Formats	Dolby Digital, Dolby Pro Logic II
DTS Formats	DTS-HD Master Audio
Tuner Type	FM/AM
Speaker Impedance	6 - 16 ohms
Weight	8.3 kg
