Panel trasero
Consulte la página que se indica entre paréntesis ( ).
q
w e
tr
yi uoQ0
q Conectores PRE OUT ············································ (C 3, 24, 25)
w Terminales de altavoces ······································· (C 3, 24, 25)
e Conector DOCK CONTROL ······················································· (9)
r Conector S-VIDEO ····································································· (9)
t Conectores VIDEO ································································· (7, 8)
y Cable de alimentación ······················································ (C 4)
u Conectores de audio digital ················································· (7, 8)
i Conectores HDMI ·························································· (C 4, 5)
o Conectores de audio analógico ········································ (7, 8, 9)
Q0 Terminales de antena FM/AM ··············································· (10)
NOTA
No toque los pines internos de los conectores en el panel trasero.
La descarga electrostática puede ocasionar daños permanentes a la
unidad.
