Denon AVR-1610 Service Manual

109
AVR-1910/1620/1610/790/590
R1207FR 00D9639005642 R,METAL FILM 1.2K-J,1W C060012265050S
R1207SL 00D9639005642 R,METAL FILM 1.2K-J,1W C060012265050S
R1207SR 00D9639005642 R,METAL FILM 1.2K-J,1W C060012265050S
R1218C 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R1218FL 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R1218FR 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R1218SL 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R1218SR 00D9639006256 R,FIXED 1WJ-10 N113135610020S
R1222C 00D9609010719 R,METAL FILM 47-J,1W C060047065060S
R1222FL 00D9609010719 R,METAL FILM 47-J,1W C060047065060S
R1222FR 00D9609010719 R,METAL FILM 47-J,1W C060047065060S
R1222SL 00D9609010719 R,METAL FILM 47-J,1W C060047065060S
R1222SR 00D9609010719 R,METAL FILM 47-J,1W C060047065060S
R1231C 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1231FL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1231FR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1231SL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1231SR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1232C 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1232FL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1232FR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1232SL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1232SR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1234C 00D9639006285 R,FIXED 1WJ-5.6K N113135656220S
R1234FL 00D9639006285 R,FIXED 1WJ-5.6K N113135656220S
R1234FR 00D9639006285 R,FIXED 1WJ-5.6K N113135656220S
R1234SL 00D9639006285 R,FIXED 1WJ-5.6K N113135656220S
R1234SR 00D9639006285 R,FIXED 1WJ-5.6K N113135656220S
R1235C 00D9639006285 R,FIXED 1WJ-5.6K N113135656220S
R1235FL 00D9639006285 R,FIXED 1WJ-5.6K N113135656220S
R1235FR 00D9639006285 R,FIXED 1WJ-5.6K N113135656220S
R1235SL 00D9639006285 R,FIXED 1WJ-5.6K N113135656220S
R1235SR 00D9639006285 R,FIXED 1WJ-5.6K N113135656220S
R1236C 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R1236FL 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R1236FR 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R1236SL 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R1236SR 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R1237C 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R1237FL 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R1237FR 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R1237SL 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R1237SR 00D9630215907 R,METAL FILM 4.7-J,1W C0604R7065050S
R1238C 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1238FL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1238FR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1238SL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1238SR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1239C 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1239FL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1239FR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1239SL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R1239SR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
