Denon AVR-1610 Service Manual

110
AVR-1910/1620/1610/790/590
CAPACITORS GROUP
C1201 00D9630324005 C,ELECT 100UF-M/100V
D04010108C240S
C1202 00D9639005804 C,ELECT 100UF-M/25V D040101084060S
C1202C 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1202FL 00D9609010133 C,ELECT 220UF-M/35V D040221085060S
C1202FR 00D9609010133 C,ELECT 220UF-M/35V D040221085060S
C1202SL 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1202SR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1203,1204 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C1209C 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1209FL 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1209FR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1209SL 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1209SR 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C1210C 00D9630338208 C,CERAMIC 470PF-K/500V D00447127D050S
C1210FL 00D9630338208 C,CERAMIC 470PF-K/500V D00447127D050S
C1210FR 00D9630338208 C,CERAMIC 470PF-K/500V D00447127D050S
C1210SL 00D9630338208 C,CERAMIC 470PF-K/500V D00447127D050S
C1210SR 00D9630338208 C,CERAMIC 470PF-K/500V D00447127D050S
C1211C 00D9630367101 C,CERAMIC 220PF-J/500V D00422106D05CS
C1211FL 00D9630367101 C,CERAMIC 220PF-J/500V D00422106D05CS
C1211FR 00D9630367101 C,CERAMIC 220PF-J/500V D00422106D05CS
C1211SL 00D9630367101 C,CERAMIC 220PF-J/500V D00422106D05CS
C1211SR 00D9630367101 C,CERAMIC 220PF-J/500V D00422106D05CS
C1212C 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C1212FL 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C1212FR 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C1212SL 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C1212SR 00D9639003194 C,FILM 0.0022UF-J/100V D02022206C060S
C1213C 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1213FL 00D9609010133 C,ELECT 220UF-M/35V D040221085060S
C1213FR 00D9609010133 C,ELECT 220UF-M/35V D040221085060S
C1213SL 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1213SR 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1214C 00D9630216100 C,CERAMIC 33PF-J/500V D00033006D050S
C1214FL 00D9630216100 C,CERAMIC 33PF-J/500V D00033006D050S
C1214FR 00D9630216100 C,CERAMIC 33PF-J/500V D00033006D050S
C1214SL 00D9630216100 C,CERAMIC 33PF-J/500V D00033006D050S
C1214SR 00D9630216100 C,CERAMIC 33PF-J/500V D00033006D050S
C1215C 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C1215FL 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C1215FR 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C1215SL 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C1215SR 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C1216C nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1216FL nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1216FR nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1216SL nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1216SR nsp C,CERAMIC 0.1UF-K/50V D011104577160S
OTHERS PARTS GROUP
CN1000 nsp CN,WIRE 5P
L000171052050S
CN1005 nsp CN,WIRE 4P L002101042620S
CN1201 nsp CN,WIRE 9P L002111092620S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
