Denon AVR-1610 Service Manual

112
AVR-1910/1620/1610/790/590
PCB VIDEO ASS'Y
Ref. No. Part No. Part Name Remarks ETRO Q'ty New
SEMICONDUCTORS GROUP
IC1600 00D2623679900 IC SN74AHCU04NSR
J040740400280S
IC1601 00D2623680902 IC SN74AHC14NSR J040741400190S
IC1602 00D2623174900 IC SN74HAHCT08 J040740800180S
IC1900 232810005504S IC BD7628F-E2 J127762800010S
IC1901 00D2623756904 IC LA73053 J127730530010S
IC1903,1904 232810005504S IC BD7628F-E2 J127762800010S
IC1905 00D9630116307 IC LC74781-9013-E J170747810010S
IC1906 963239004170S IC MM74HC4051MX J040744051020S
IC1907 963239003470S IC NJM2586AM J171258600010S
IC1908 00D9630218807 IC BU4094BCF-E2 J040140940030S
IC1909 00D2623174900 IC SN74HAHCT08 J040740800180S
Q1900,1901 00D9630120801 TR KRC102S J522010200210S
Q1902 00D9630148508 TRKTA1504S J520015040150S
Q1903,1904 00D9630121509 TR KTC3875S J522038750210S
Q1905 00D9630148508 TRKTA1504S J520015040150S
Q1906 00D9630120801 TR KRC102S J522010200210S
Q1907 00D9630121606 TR KRC107S J522107S00210S
Q1908 00D9630148508 TRKTA1504S J520015040150S
D1600 00D9630245100 D,SWITCHING KDS226ST1(C3) 1910, 790 K005022600020S
D1601 00D9630245100 D,SWITCHING KDS226ST1(C3) K005022600020S
D1602 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D1603-1605 00D9630341305 D,ESD IMSA-6802-01A K067680200010S
D1606,1607 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D1900-1905 00D9630355401 D,SWITCHING KDS4148U K005041480030S
CAPACITORS GROUP
C1600 00D9639005862 C,ELECT 47UF-M/16V 1910, 790
D040470083080S
C1601 nsp C,CERAMIC 0.1UF-K/50V 1910, 790 D011104577160S
C1603 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C1604 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1606,1607 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1608 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C1609 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1611 00D9609010010 C,ELECT 4.7UF-M/50V 1910, 790 D0404R7087250S
C1612 nsp C,CERAMIC 0.1UF-K/50V 1910, 790 D011104577160S
C1613 00D9609010010 C,ELECT 4.7UF-M/50V D0404R7087250S
C1614 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1615 00D9609010010 C,ELECT 4.7UF-M/50V D0404R7087250S
C1616 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1617 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1618 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1620 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1900,1901 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1902 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1903 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1904 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1905 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1906 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C1907 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C1908 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C1909 nsp C,CERAMIC 0.1UF-K/50V D011104577160S

Denon AVR-1610 Specifications

General

Channels	5.1
Power Output	75 W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
HDMI Inputs	4
HDMI Outputs	1
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Surround System Class	5.1 channel
HDMI Switching	Yes
3D Technology	Yes
Input Sensitivity/Impedance	200 mV / 47 kOhm
HDMI Version	1.3a
Dolby Formats	Dolby Digital, Dolby Digital Plus
DTS Formats	DTS, DTS Neo:6, DTS 96/24
Audyssey	MultEQ
Amplifier Output Details	75 W per channel at 8 ohms, 20 Hz to 20 kHz, 0.08% THD
Response Bandwidth	10Hz - 100kHz
Audio D/A Converter	192 kHz/24-bit
Frequency Response	10 Hz to 100 kHz
Video Inputs/Outputs	Composite, Component
Audio Inputs/Outputs	Digital Optical
